Heavy Duty Slotting Machine Manufacturers


INTRODUCTION TO SLOTTING MACHINE


Working principle of slotting machine is very simple. In the slotting machine, work item is placed in a vertical position on the bed. And then cutting tools move in reciprocating action to perform the operation and shed the additional material from the work item. In the slotting machine cutting action is executed at the downward stroke to cut the extra piece or material from the work piece.

WORKING PRINCIPLE OF SLOTTING MACHINE


Working principle of slotting machine is very simple. In the slotting machine, work item is placed in a vertical position on the bed. And then cutting tools move in reciprocating action to perform the operation and shed the additional material from the work item. In the slotting machine cutting action is executed at the downward stroke.

USE OF SLOTTING MACHINES IN INDUSTRIES


  • Slots of Different shaps and cutting grooves
  • Construct a regular and irregular surfaces for internal and external.
  • Use for handling large workpiece
  • slotting machine used a construction of mechnical convex, concave, and semi circular surfaces of machines

IMPORTANT PARTS OF SLOTTING MACHINE


To understand the working of slotting machine in a better way, Esskay machines the best slotting machine manufacturer will help to know the parts of slotting machines, and their importance in the operation of the slotter machine.

BED

The bed is one of the most important parts of slotting machine and due to the required strength. slotting machine bed is made of cast iron.Bed of the slotting machine supports table, ram, column, etc.

TABLE

The table is used to hold the work item and it is also made up of cast iron.Rotatory table of slotting machine is round in shape and places above the cross-slides. The rotation of table operated by power with the gear connected to under the table. Table of the slotting machine can be adjusted in the directions like longitude and crosswise

RAM

Ram is placed to support the reciprocating action ie forward and backwards. Ram also carries the cutting tool which performs the cutting operation in the vertical direction

CROSS-SLIDE

Cross-slide movesin the parallel direction to the column. The movements of cross-slides controlled by hand or power supply

SADDLE

Saddles are build on the guideways and moved away from the column by manually or by power supply

HAND WHEELS

Hand wheels support the rotation of the table while adjusting the work item.

COLUMN

Colum again is made of cast iron since it supports table, table and driving mechanism.

TYPES OF SLOTTING MACHINES


1. PUNCH SLOTTING MACHINE

Punch slotting machine is a heavy duty machine basically designed for shedding large chunks of the amount of metal.

2. TOOL ROOM SLOTTING MACHINE

Tool room slotting machine operates to give finishing to the cuts. This machine operates at high speed but gives light cuts.

3. PRODUCTION SLOTTING MACHINE

This is again heavy duty machinery where in base and frame are heavy and made up of cast iron.

Esskay Lathe and Machine Tools is one of the reputed and trusted slotting machine manufacturer who operates in Delhi, Mumbai, Pune and another region in India. Esskay is the trusted brand in the manufacturing of slotter machine, drilling machine , lathe machine, shapermachine, milling machine etc.
